Connecting Rod Yamaha YZ 125 1986-1996 8104
Connecting Rod Yamaha YZ 125 1986-1996
Hot Rods 8104
All connecting rod kits include crank pins, crank pin bearings, washers & wrist Pins (when applicable)
- Manufactured from hot-rolled ASTM 4115 and case-hardened to 58 - 62 Rc
- Shot peened to eliminate surface stress risers
- Small ends are double drilled to supply extra lubrication and cooling to the wrist pin bearing
Technical Specifications:
Big End Bearing (mm): 22x29x16.7
Big End Bore (mm): 29.00
Big End Width (mm): 16.90
Center To Center (mm): 105.00
Pin Diameter (mm): 22.00
Pin Length (mm): 54.30
Small End Bearing (mm): 16x20x19.3
Small End Bore (mm): 20.00
Small End Width (mm): 16.90
Washer Thickness (mm): 1
