Connecting Rod Yamaha YZF 250 2014-on 8706
Yamaha YZF 250 2014 - 2024 WRF 250 2015 - 2024
- All connecting rod kits include crank pins, crank pin bearings, washers & wrist Pins (when applicable)
- Manufactured from hot-rolled ASTM 4115 and case-hardened to 58 - 62 Rc
- Shot peened to eliminate surface stress risers
- Small ends are double drilled to supply extra lubrication and cooling to the wrist pin bearing
Technical Specifications:
Big End Bearing (mm): 30 x 38 x 17.8
Big End Bore (mm): 38.00
Big End Width (mm):17.95
Center To Center (mm): 92.50
Pin Diameter (mm): 30.00
Pin Length (mm): 54.80
Small End Bearing (mm): N/A
Small End Bore (mm): 16.00
Small End Width (mm): 15.05
Washer Thickness (mm): N/A
