Connecting Rod - Hot Rods

Connecting Rod Yamaha YZF 250 / WRF 250 2001-2002

Stops the knock that a worn big-end bearing leaves behind.

Connecting Rod Yamaha YZF 250 / WRF 250 2001-2002
Actual Verified Photo Verified: actual photo of product
Brand
Part No:
HR.8618
Condition:
New
Delivery:
2-3 working days
Delivery info
WAS £139.95
£119.00(£99.17 ex VAT)
You save £20.95

Key benefits of fitting this part

Restores correct bottom-end geometry A fresh rod restores correct geometry and tolerances at the heart of the bottom end.
Protects the whole engine Prevents a failed rod from taking out the crankcase entirely.
Essential once knocking starts Essential once knocking or excess play is found at the big end.
Brand
Part No:
HR.8618
Condition:
New
Delivery:
2-3 working days
Delivery info

Product description

  • All connecting rod kits include crank pins, crank pin bearings, washers & wrist Pins (when applicable)
  • Manufactured from hot-rolled ASTM 4115 and case-hardened to 58 - 62 Rc
  • Shot peened to eliminate surface stress risers
  • Small ends are double drilled to supply extra lubrication and cooling to the wrist pin bearing

Technical Specifications:

Big End Bearing (mm):

30x38x17.8

Big End Bore (mm):

38.00

Big End Width (mm):

17.97

Center To Center (mm):

93.50

Pin Diameter (mm):

30.00

Pin Length (mm):

54.80

Small End Bearing (mm):

Bushing

Small End Bore (mm):

16.00

Small End Width (mm):

14.95

Washer Thickness (mm):

Not Used
